The Perfect Involution: Oil-rubbed Bronze, 220 Volt Cherry/walnut Perfect Gift [UJPGdWhH]

Features

• Compatible only with 220 volt electricity

Specifications

• Length: 17 Inches
• Weight: 17.85 Lbs
• Width: 10.5 Inches
• Height: 17 Inches
• Product Line: Involution
• Light Kit Included: No
• Housing Diameter: 7.6
• Included Control: CW40-220
• Included Control Type: Wall
• Ceiling to Bottom (No LK): 17.54
• Blade Pitch Degrees: 14
• Blade Reversible: Yes
• Number of Blades: 2
• Blade Sweep: 52
• Blade Finish: Cherry/Walnut
• Blade Material: Wood
• Blade Finish Method Type: Paper Overlay
• Product Finish: Oil-Rubbed Bronze
• Leadwire: 80
• Downrod Length: 6
• Canopy Diameter: 6.4375
• Canopy Height: 2.625
• Motor Type: AC
• Motor Size: 153 x 18
• Motor Finish Method Type: PAINTED
• Reverse Switch Location: MOTOR HOUSING
• Number of Speeds: 3
• Maximum Slope Degree: 27
• CFM Low: 2954
• CFM Medium: 3302
• CFM High: 3780
• Watts Low: 19
• Watts Medium: 23
• Watts High: 29
• Airflow Efficiency Low: 155
• Airflow Efficiency Medium: 144
• Airflow Efficiency High: 130
• RPM Low (II): 98
• RPM Medium (IV): 113
• RPM High (VI): 125
• Current Draw Low: 0.11
• Current Draw Medium: 0.12
• Current Draw High: 0.13
• Country of Manufacture: CHINA
• IP Rating: IP20
• Voltage: 240V
• Voltage Cycles: 50HZ
• Warranty Type: Limited Lifetime Warranty
• Housing Diameter: 7.6 Housing Diameter Inches

Certifications

• Regulated Product Yes or No: No
• Exempt from DOE Procedure: Yes
• DOE-FTC Uploaded: No
• CEC Uploaded: No

Downloads
