Fast Delivery Flipsky Inrunner Brushless Dc 65111 Motor 160kv 3000w For Surfing Boat Underwater Thruster |hydro | Efoil At A Low Price [qiNDcPg5]

Customized (please leave notes)

Spec:

• Voltage range: 6-20S (25.2-84V)
• Max power: 3000W;
• Continuous power: 1500W
• Peak current: 70A;
• Continuous current: 30A
• Motor KV: 160KV
• Max spin speed(RPM): 8064
• Size: OD65*L111mm
• Shaft diameter: 10mm
• Motor pole: 6pcs; 3 pairs
• Motor stator slot: 12
• Waterproof rate: IP68
• Lead wires extension: 12AWGx1400mm

The thrust under the condition of reaching this voltage and current as below:

• 48.5V 2.7A 5KG
• 48.5V 8.2A 10KG
• 48.5V 18.2A 15KG
• 48.5V 20A 17KG
• 48.5V 25A 19KG
• 48.5V 30A 21KG
• 48.5V 35A 23KG

Drawing:

PROP GUARD Round With Thread Shaft Diagram:

Aluminum Alloy 7 1/4X5 Propeller(White) Diagram:

Nylon 3.8 inches Propeller(Black) for Stepped Shaft Diagram:

160KV 36V Motor Curve Diagram link

160KV 48V Motor Curve Diagram link

160KV 60V Motor Curve Diagram link
